Vibrating feeder
Vibrating feeder, also known as vibrationfeeder, is a new type, energy-saving, universal application feeding device, mainly used for the feeding massive, granular and powdery materials. It is often used with vibrating conveyors, vibrating screens, belt conveyors, bucket elevators, crushers, etc. It also can be used in the process of automatic weighing, quantitative packaging, and automatic control. It can realize the automation of flow operations.It is ideal feeding equipment for metallurgy, coal, thermal power, fire-resistant, glass, building materials, light industry, chemical, machinery, and food industries.
We're here to help
Easy ways to get the answers you need.
Contact Now
Contact Now
Product introduction
Vibrating feeder, also known as vibrationfeeder, is a new type, energy-saving, universal application feeding device, mainly used for the feeding massive, granular and powdery materials. It is often used with vibrating conveyors, vibrating screens, belt conveyors, bucket elevators, crushers, etc. It also can be used in the process of automatic weighing, quantitative packaging, and automatic control. It can realize the automation of flow operations.It is ideal feeding equipment for metallurgy, coal, thermal power, fire-resistant, glass, building materials, light industry, chemical, machinery, and food industries.
Technical features and advantages
Simple structure, light weight, low noise, reliable work, large feeding capacity, easy installation and maintenance.
Using self-synchronizing principle of special vibration motor, it can start quickly, work stably, and stop smoothly.
Due to the ability to instantaneously change and open and close streams, the dosing volume is highly accurate.
This series of vibrating feeder is not suitable for explosion-proof occasions.
According to the structure can be designed as open, closed type.
The machine has the advantages of compact structure, convenient use and maintenance, continuous and uniform feed, long service life and so on.
The service life of the complete machine is 5 years. The service life of the vibration motor is 1 year.
Power distribution control device for remote control.
According to the requirements of site, it can be designed as a seat or hanging type.
Technical Parameter
|
Model
|
Material size(mm)
|
Capacity (t/h)
|
Motor
Model
|
Power
(kw)
|
HZ
|
Aplitude
(mm)
|
Excit Force
(KN)
|
Weight(kg)
|
|
|
Shut
|
Open
|
||||||||
|
ZG-25
|
60
|
25
|
YZO-2.5-4
|
0.25×2
|
25
|
2-3
|
2.5×2
|
240
|
174
|
|
ZG-30
|
80
|
30
|
YZO-5-4
|
0.4×2
|
25
|
2-3
|
5×2
|
256
|
184
|
|
ZG-50
|
90
|
50
|
YZO-5-4
|
0.4×2
|
25
|
2-3
|
5×2
|
295
|
235
|
|
ZG-60
|
90
|
60
|
YZO-5-4
|
0.4×2
|
25
|
2-4
|
5×2
|
302
|
242
|
|
ZG-80
|
100
|
80
|
YZO-8-4
|
0.75×2
|
25
|
2-4
|
8×2
|
312
|
256
|
|
ZG-100
|
150
|
100
|
YZO-8-4
|
0.75×2
|
25
|
2-5
|
8×2
|
384
|
321
|
|
ZG-200
|
180
|
200
|
YZO-17-4
|
1.5×2
|
25
|
2-5
|
17×2
|
432
|
372
|
|
ZG-300
|
200
|
300
|
YZO-17-4
|
1.5×2
|
25
|
3-5
|
17×2
|
636
|
556
|
|
ZG-400
|
250
|
400
|
YZO-20-4
|
2×2
|
25
|
3-5
|
20×2
|
686
|
606
|
|
ZG-500
|
300
|
500
|
YZO-20-4
|
2×2
|
25
|
3-5
|
20×2
|
1016
|
986
|
|
ZG-750
|
350
|
750
|
YZO-30-4
|
2.5×2
|
25
|
4-6
|
30×2
|
1358
|
1030
|
|
ZG-1000
|
400
|
1000
|
YZO-50-4
|
3.75×2
|
25
|
4-6
|
50×2
|
1446
|
1156
|
