Pulverized coal vibrating screen
Pulverized coal vibrating screen
Pulverized coal vibrating screen is a special vibrating screen according to the special requirement of pulverized coal screening in blast furnace pulverized coal injection process, mainly to prevent wood chips, fibers and other impurities from entering the pulverized coal bunker, and to ensure the normal transportation of pulverized coal in pipelines.
We're here to help
Easy ways to get the answers you need.
Contact Now
Contact Now
Product introduction
Pulverized coal vibrating screen is a special vibrating screen according to the special requirement of pulverized coal screening in blast furnace pulverized coal injection process, mainly to prevent wood chips, fibers and other impurities from entering the pulverized coal bunker, and to ensure the normal transportation of pulverized coal in pipelines.
Technical features and advantages
l The pulverized coal vibrating screen (pulverized coal screen) has the advantages of good screening effect, safe and reliable work, good sealing performance, and less negative effects on the foundation.
l The screen machine is equipped with a secondary vibration isolation system. When the coal powder screen is in operation, the dynamic load transmitted to the foundation is small and can be installed on the floor.
l The screen surface is a flat-top stainless steel wire woven screen, which is tightened with a hook plate.
l Two vibration motors are used as the vibration source, which is easy to maintain.
l The service life of the complete machine is 5 years, and the service life of the vibration motor is 1 year.
Technical Parameter
|
Model
|
ZSM-50×140
|
ZSM-80×150
|
ZSM-90×200
|
ZSM-100×300
|
|
Capacity(t/h)
|
15
|
30
|
50
|
65
|
|
Cuting point(mm)
|
3×3
|
5×5
|
5×5
|
5×5
|
|
Motor model
|
YZO-10-6
|
YZO-20-6
|
YZO-30-6
|
YZO-50-6
|
|
Motor power(kw)
|
0.75×2
|
2.0×2
|
2.5×2
|
3.7×2
|
|
Frequency(hz)
|
16
|
16
|
16
|
16
|
|
Double Amplitude(mm)
|
5-7
|
5-7
|
5-7
|
5-7
|
|
Single dynamic load(N)
|
200
|
750
|
1000
|
1200
|
