Dewatering Screen
The structural feature is that the feeding section is at an angle of 45 degrees with the horizontal direction, and the middle section and the discharging end are at an angle of -5 degrees with the horizontal direction. This design helps the material quickly form a bed at the infeed end, and the movement of the material on the -5 degree screen surface is slowed down, helping the moisture through the bed through the screen. The high-frequency dehydration screen is driven by two oscillating motors that are mounted on the oscillating beam in counter-rotation or are driven by an exciter, using imported SKF or FAG bearings.
Learn More
Power screen
Power screen is the screening equipment developed by our company to solve the the screen mat plugging problem in screening wet and sticky materials, especially for the screening of less than 10mm wet sticky materials.
Learn More
Pulverized coal vibrating screen
Pulverized coal vibrating screen is a special vibrating screen according to the special requirement of pulverized coal screening in blast furnace pulverized coal injection process, mainly to prevent wood chips, fibers and other impurities from entering the pulverized coal bunker, and to ensure the normal transportation of pulverized coal in pipelines.
Learn More
Cold Screen
The cold screen is a new type of vibrating screen which is based on our company's patented product- the elastic exciter, as the vibration source. It is mainly used for the grading operation of cold sinters with temperatures below 150°C in the metallurgical industry. The series of cold screens can be installed on the left or right side according to the conditions of the work site. According to the different installation positions of the motor and exciter, it is mainly used in the material classification of mining, metallurgy, coal, thermal power, fire-resistant, building materials, power, chemical and other industries.
Banana Screen
The banana vibrating screen is a self-synchronizing heavy-duty equal-thickness screen. The screen box is similar to the banana shape. The screen beam adopts the box-shaped beam. The vibrating screen transmission system is passed by the motor through the pulley and the V-belt and then transmitted by the cardon shaft. The exciters are connected by an intermediate cardon shaft. It is widely used in coal grading, desliming, dehydration, and removal. It can also be used in the screening treatment of mining material selection operations.
Learn More
Circular Screen
Circular screen is a kind of multi-deck and high-efficiency new vibrating screen. Circular vibrating screens are widely used in the screening of dry materials in the mining, building materials, transportation, energy, and chemical industries.
Learn More
Hot screen
The hot screen is mainly used for the grading of medium or small size sinters with a temperature of 600-800°C in the metallurgical industry, and completes the uniform cloth operation to the cooling equipment. According to the conditions of the work site, the motors of hot screens can be installed on the left side or the right side; depending on the installation position of the motor or exciter, the hot screens can be divided into upper vibration and lower vibration type. According to user requirements, our company can design and manufacture various hot screens.
Learn More
Linear Screen
The linear screen is a type of vibrating screen which is based on our company's patented product- the GK-exciter, as the vibration source. It is mainly used for the grading operation of cold materials with temperatures below 150°C . The series screens can be installed on the left or right side according to the conditions of the work site.
